Flow Cone Apparatus Manufacturer,Supplier and Exporter in Uganda

Flow Cone Apparatus

Product Code : EDS-CTLE-11361

The apparatus comprises a metal stand supporting the stainless steel cone having inside dimensions of 150 mm inside upper dia. x 280 mm height.
Lss Uganda used for determining the flow properties of mortars, grouts, muds and many other type of fluid materials.
When fit with the 10 mm nozzle the total height is 350 mm.
The apparatus, as prescribed by Lss Uganda is supplied complete with 150 mm dia. sieve 1.5 mm opening, 10 mm dia. nozzle with fitting bush and 1 liter cap. cup.
It can also be fit with other nozzles 8, 9, 11, and 13 mm int. dia.
Nozzle 8, 9, 10, 11 and 13 mm
Cup 1 lt
Stand
Flow Cone,
Sieve 1, 5 mm
Fitting Bush
Weight approx.: 10 kg
